Construction: Attractive scratch and mar-resistant laminate. Detection Heads and Support: heavy duty aluminum.
Overall Exterior Size: Width 35" (0.90 m), Height 87" (2.21 m), Depth 23" (0.58 m)
Interior Size (passageway): Width 30" (0.76 m), Height 80" (2.03 m), Depth 23" (0.58 m)
Detection Zones: 33 zones (left, right and center); visual and audible alarms with a built-in dry contact alarm relay
Regulatory Information: Meets international airport standards such as TSA, ECAC, STAC, AENA, CJIAC, DFT. Meets additional standards and requirements such as USMS, NIJ-0601.02, NILECJ. Meets Electrical Safety and Compatibility Requirements for CE, FCC, CSA, IEC, ICNIRP, IEEE.
Tamper-proof: All settings are secured with a key lock and two levels of access codes. Further security with a cabinet lock that access to physical cables, connectors and electronics.
Easy assembly: The PD 6500i’s modular for a quick and simple assembly of its four (4) sub-assemblies using only eight (8) screws and three (3) internal cable connections.
